CAT8 Ethernet Network Cable  pass the fluke test 2000MHz 40GB 1M 2M 5M 10M patch cable

CAT8 Ethernet Network Cable  pass the fluke test 2000MHz 40GB 1M 2M 5M 10M patch cable

Copper Patch Cable Series

 2000MHz  CAT 8  High-Speed 40Gbps Ethernet Patch Cable

Fluke test pass

  • Type: Cat8
  • Bandwidth: 2000MHz
  • Speed: 40 Gigabit
  • Conductor: Stranded 24/26/28AWG
  • Lengths: 0.2m/0.3m/0.5m/1m/1.5m/2m/3m…30m
  • Colors: Blue/grey/black/green/yellow/red/white…
  • Package: 1pcs/PE bag
  • Approvals: CE, RoHS&REACH
  • Warranty: Lifetime

Whatsapp Now
Require A Quote

Easy Link’s latest PIMF cat8 patch cord is designed for 40G 2000MHz dada transmission on copper cabling, which can  pass category 8 channel test at MAX 30 meters. Meets the standards ANSI/TIA-568-C.2-1 . Component with four 28AWG 7/0.12mm stranded bare copper twisted-pair wires(or 26awg and 24awg), insulated with high density PE, each pair twisted and individually shielded with AL foil, and with the second AL foil or braid shielding and Cat 8 RJ45 shielded modular plugs. COMNEN’s Cat 8 patch cable features four individually shielded pairs as well as an overall cable shield to protect the signals from crosstalk and EMI. Works with category8 Ethernet cable and Cat8 keystone jack, we can provide you with full cat8 solutions.

Physical Characteristics

• Cable Type – Cat8 FFTP/SFTP
• Connector Type(s) – RJ45 Male
• Wiring Scheme – T568A or T568B
• Temperature Rating – -20°C to +75°C
• Voltage Rating – 30V

———————————————————————————————————————————————

Conductor (Qty. 4 twisted pair)

• Conductor Type – 28AWG(7/0.12), Bare Copper
• Insulation – HDPE
• Dimeter – 1.10±0.05mm
• Pair Identification:
• Pair1=Orange, Orange-White
• Pair2=Blue, Blue-White
• Pair3=Green, Green-White
• Pair4=Brown, Brown-White

Connector Type (Qty. 2)

• Connector Type – Shielded 8P8C (RJ45)
• Gender – Male
• Connector Material – PC
• Contact Material – Copper Alloy, Gold Plating – 50µm
• Hood Material – Molded PVC

Overall Cable

• Jacket – PVC/LSZH/TPE
• Minimum Average Thickness – 0.60mm
• Outer Diameter – 6.0 ± 0.15mm

———————————————————————————————————————————————

Electrical Characteristics

• Conductor DC Resistance – 22.7Ω/100m (maximum)
• Impedance – 100Ω
• Capacitance – 5600pf/100m
• Propagation Delay – 545ns/100m (maximum)
• Delay Skew – 45ns/100m (maximum)

———————————————————————————————————————————————

Product Application

• Horizontal networks installation
• 40Gigabit; 10Gigabit;Gigabit 1000 BASE-T; 100 BASE-T; 10 BASE-T (IEEE 802.3)
• Adapters, Hubs, Switches, Routers, DSL/Cable Modems, Patch Panels etc.

Product Description
Type
CAT8 F/FTP Patch Cord
Data transfer rate
40Gbps
Conductor material
oxygen-free copper
Transmission frequencies
2000MHz
Facing material
PVC/LSZH
length
0.5m~20m/OEM
Standard
ANSI/EIA/TIA-568B
Overall Outside Diameter
6.0mm
Shielding
F/FTP
Operating temperature
-20℃/+70℃
AWG
28AWG strand wire
Bending radius
4 times the cable diameter
40Gbps Ethernet Cable RJ45 Cat 8 2000MHz S/FTP Cat8 Patch Cable Patch Cord Soft Jacket 0.5M 1M 2M 3M 5M 10M 15M 20M 25M

40Gbps Ethernet Cable RJ45 Cat 8 2000MHz S/FTP Cat8 Patch Cable Patch Cord Soft Jacket 0.5M 1M 2M 3M 5M 10M 15M 20M 25M

Copper Patch Cable Series

CAT 8 Ethernet Cable High-Speed 40Gbps SFTP Network Cable RJ45 with Gold Plated Patch Cord

  • Type: Cat8
  • Bandwidth: 2000MHz
  • Speed: 40 Gigabit
  • Conductor: Stranded 24/26/28AWG
  • Lengths: 0.2m/0.3m/0.5m/1m/1.5m/2m/3m…30m
  • Colors: Blue/grey/black/green/yellow/red/white…
  • Package: 1pcs/PE bag
  • Approvals: CE, RoHS&REACH
  • Warranty: Lifetime

Whatsapp Now
Require A Quote

Easy Link’s latest PIMF cat8 patch cord is designed for 40G 2000MHz dada transmission on copper cabling, which can  pass category 8 channel test at MAX 30 meters. Meets the standards ANSI/TIA-568-C.2-1 . Component with four 28AWG 7/0.12mm stranded bare copper twisted-pair wires(or 26awg and 24awg), insulated with high density PE, each pair twisted and individually shielded with AL foil, and with the second AL foil or braid shielding and Cat 8 RJ45 shielded modular plugs. COMNEN’s Cat 8 patch cable features four individually shielded pairs as well as an overall cable shield to protect the signals from crosstalk and EMI. Works with category8 Ethernet cable and Cat8 keystone jack, we can provide you with full cat8 solutions.

Physical Characteristics

• Cable Type – Cat8 FFTP/SFTP
• Connector Type(s) – RJ45 Male
• Wiring Scheme – T568A or T568B
• Temperature Rating – -20°C to +75°C
• Voltage Rating – 30V

———————————————————————————————————————————————

Conductor (Qty. 4 twisted pair)

• Conductor Type – 28AWG(7/0.12), Bare Copper
• Insulation – HDPE
• Dimeter – 1.10±0.05mm
• Pair Identification:
• Pair1=Orange, Orange-White
• Pair2=Blue, Blue-White
• Pair3=Green, Green-White
• Pair4=Brown, Brown-White

Connector Type (Qty. 2)

• Connector Type – Shielded 8P8C (RJ45)
• Gender – Male
• Connector Material – PC
• Contact Material – Copper Alloy, Gold Plating – 50µm
• Hood Material – Molded PVC

Overall Cable

• Jacket – PVC/LSZH/TPE
• Minimum Average Thickness – 0.60mm
• Outer Diameter – 6.0 ± 0.15mm

———————————————————————————————————————————————

Electrical Characteristics

• Conductor DC Resistance – 22.7Ω/100m (maximum)
• Impedance – 100Ω
• Capacitance – 5600pf/100m
• Propagation Delay – 545ns/100m (maximum)
• Delay Skew – 45ns/100m (maximum)

———————————————————————————————————————————————

Product Application

• Horizontal networks installation
• 40Gigabit; 10Gigabit;Gigabit 1000 BASE-T; 100 BASE-T; 10 BASE-T (IEEE 802.3)
• Adapters, Hubs, Switches, Routers, DSL/Cable Modems, Patch Panels etc.

Product Description
Type
CAT8 F/FTP Patch Cord
Data transfer rate
40Gbps
Conductor material
oxygen-free copper
Transmission frequencies
2000MHz
Facing material
PVC/LSZH
length
0.5m~20m/OEM
Standard
ANSI/EIA/TIA-568B
Overall Outside Diameter
6.0mm
Shielding
F/FTP
Operating temperature
-20℃/+70℃
AWG
28AWG strand wire
Bending radius
4 times the cable diameter
China manufacturer 40G 2000MHz Cat8 Patch Cord Copper PIMF RJ45 Ethernet Network Patch Cable

China manufacturer 40G 2000MHz Cat8 Patch Cord Copper PIMF RJ45 Ethernet Network Patch Cable

Copper Patch Cable Series

CAT 8 Ethernet Cable High-Speed 40Gbps SFTP Network Cable RJ45 with Gold Plated Patch Cord

  • Type: Cat8
  • Bandwidth: 2000MHz
  • Speed: 40 Gigabit
  • Conductor: Stranded 24/26/28AWG
  • Lengths: 0.2m/0.3m/0.5m/1m/1.5m/2m/3m…30m
  • Colors: Blue/grey/black/green/yellow/red/white…
  • Package: 1pcs/PE bag
  • Approvals: CE, RoHS&REACH
  • Warranty: Lifetime

Whatsapp Now
Require A Quote

Easy Link’s latest PIMF cat8 patch cord is designed for 40G 2000MHz dada transmission on copper cabling, which can  pass category 8 channel test at MAX 30 meters. Meets the standards ANSI/TIA-568-C.2-1 . Component with four 28AWG 7/0.12mm stranded bare copper twisted-pair wires(or 26awg and 24awg), insulated with high density PE, each pair twisted and individually shielded with AL foil, and with the second AL foil or braid shielding and Cat 8 RJ45 shielded modular plugs. COMNEN’s Cat 8 patch cable features four individually shielded pairs as well as an overall cable shield to protect the signals from crosstalk and EMI. Works with category8 Ethernet cable and Cat8 keystone jack, we can provide you with full cat8 solutions.

Physical Characteristics

• Cable Type – Cat8 FFTP/SFTP
• Connector Type(s) – RJ45 Male
• Wiring Scheme – T568A or T568B
• Temperature Rating – -20°C to +75°C
• Voltage Rating – 30V

———————————————————————————————————————————————

Conductor (Qty. 4 twisted pair)

• Conductor Type – 28AWG(7/0.12), Bare Copper
• Insulation – HDPE
• Dimeter – 1.10±0.05mm
• Pair Identification:
• Pair1=Orange, Orange-White
• Pair2=Blue, Blue-White
• Pair3=Green, Green-White
• Pair4=Brown, Brown-White

Connector Type (Qty. 2)

• Connector Type – Shielded 8P8C (RJ45)
• Gender – Male
• Connector Material – PC
• Contact Material – Copper Alloy, Gold Plating – 50µm
• Hood Material – Molded PVC

Overall Cable

• Jacket – PVC/LSZH/TPE
• Minimum Average Thickness – 0.60mm
• Outer Diameter – 6.0 ± 0.15mm

———————————————————————————————————————————————

Electrical Characteristics

• Conductor DC Resistance – 22.7Ω/100m (maximum)
• Impedance – 100Ω
• Capacitance – 5600pf/100m
• Propagation Delay – 545ns/100m (maximum)
• Delay Skew – 45ns/100m (maximum)

———————————————————————————————————————————————

Product Application

• Horizontal networks installation
• 40Gigabit; 10Gigabit;Gigabit 1000 BASE-T; 100 BASE-T; 10 BASE-T (IEEE 802.3)
• Adapters, Hubs, Switches, Routers, DSL/Cable Modems, Patch Panels etc.

Product Description
Type
CAT8 F/FTP Patch Cord
Data transfer rate
40Gbps
Conductor material
oxygen-free copper
Transmission frequencies
2000MHz
Facing material
PVC/LSZH
length
0.5m~20m/OEM
Standard
ANSI/EIA/TIA-568B
Overall Outside Diameter
6.0mm
Shielding
F/FTP
Operating temperature
-20℃/+70℃
AWG
28AWG strand wire
Bending radius
4 times the cable diameter
1U Cat6A Shielded STP 48 Ports Inline Coupler Patch Panel

1U Cat6A Shielded STP 48 Ports Inline Coupler Patch Panel

Copper Cabling, High Density Unloaded Patch Panel

easy link cat6A stp 1U 48 ports inline coupler

10G Support 19″ 1U48 Port Cat6A Shielded STP Patch Panel loaded with Inline Keystone

Coupler Patch Panel STP Shielded 19-Inch with Removable Back Bar, 1U Network Patch Panel for Cat7, Cat6, Cat6A, Cat5e, Cat5 Cabling

Connector Type RJ45
Cable Type HDMI, VGA, Ethernet
Connector Gender Female-to-Female
Unit Count 1 Count
Whatsapp Now
Require A Quote

Patch Panel 48 Port Cat6A with Inline Coupler Built for Easy Use, Excellent Speed, and Reliable Connectivity

Easy Link ethernet patch panel support excellent performance transmission up to10-Gigabit, compatible with the TIA/EIA 568-C.2 standard and cat7, cat6a, cat6, cat5e, cat5e UTP, and STP cabling system.

Standard 19-inch 1u patch panel suitable for Rackmount, Wallmount, or cabinets.

This Cat6A with a thick steel detachable back bar. With zip ties, the back bar helps with cable management and takes some stress off the coupler, improves the working stability of the network connection port, and avoids keystone loose and the occurrence of network failures.

Cat6A patch panel came with 10g couplers making it easier to connect the cables.

Use this to replace a punch-down patch panel.

Plug and play on both sides for ethernet cables.

This 19-rack blank panel is less prone to failure as well.

CAT6A passthrough coupler tested full 10 gigabytes certified.

Clean up the look of your cabinet or wall mount in 10 minutes.

Inline modular patch panel much better than punching down Keystones

These cat6A shielded patch panel were easy to install and use. Pass through design is more friendly to non-professional persons since it is use terminated cables and is plugged directly into switches.

Coupler patch panel lets you don’t have to spend time wiring Cat5/6 in order to get your system up and running.

Just several steps are needed as follows:

1. Plug all network cables into the back of the keystone loaded on shielded patch panel cat6a.

2. Assembly detachable back bar into the patch panel

3. Fasten the network cable onto the back bar to the sturdy cable and back bar. This step is very important to secure the keystone, cable, and back bar.

4. Put the whole patch panel onto a standard 19-inch wall mount and screw the screw included.

4. Put the whole patch panel onto a standard 19-inch wall mount and screw the screw included.

Shielded High Density Patch Panel, 1U 48-Port Blank Patch Panel

Shielded High Density Patch Panel, 1U 48-Port Blank Patch Panel

Copper Cabling, High Density Unloaded Patch Panel

19″ 1U RJ45 Cat.6A Cat.6 STP FTP Shielded Blank Unloaded  Patch Panel

This easy-to-install High-Density Patch Panel is perfect for larger network solutions. Get up to 48 different ethernet connections with this 48-Port patch panel. Easily snap in the keystone jacks of your choice. Great for combining with slim-designed connectivity for extra room and performance. Mount on to the wall of your home or install in a network enclosure. This horizontal patch panel is versatile for many different applications.

Features

  • High-density solution for up to 48 connectors
  • Shielded for protection from EMI
  • Set up in your home or business network
  • Compatible with Cat6, Cat6A, and Cat8 keystone jacks
  • Stackable patch panel with 1U



Whatsapp Now
Require A Quote
Type Patch Panel
Ports 48
Color Steel
Port Type Fits Cat6, Cat6A, Cat8
Length 19 Inches
Model Blank
Contact Compatibility -10°C to 60°C
Storage temperature range -40°C to 68°C
Humidity 10%~90%RH



Q:  Will Cat6 jacks fit alongside each other?

A:  Cat6 keystone jacks whether 90° or 180° will fit along side each other in the 48 ports

Q:  Can you use this shielded patch panel with unshielded keystone jacks?

A:  Absolutely! This shielded 48 port patch panel is perfect to use with shielded or unshielded keystone jacks. If your cable is shielded you want to use shielded jacks and if your cable is unshielded you want to use unshielded connectors.

Q:  Can this fit Cat8 keystone jacks?

A:  Yes, this patch panel is compatible with our Cat8 jacks

High quality CAT6A Network cables cat6a 28AWG Ultra Slim Ethernet Patch cord

High quality CAT6A Network cables cat6a 28AWG Ultra Slim Ethernet Patch cord

Copper Cabling, Copper Patch Cable Series

cat6a 28AWG Ultra Slim Ethernet Patch cord From Easy Link

cat6a 28AWG Ultra Slim Ethernet Patch cord

  • Type:Cat6A
  • Bandwidth:500MHz
  • Speed:10 Gigabit
  • Conductor:Stranded 28AWG
  • Lengths:0.2m/0.3m/0.5m/1m/1.5m/2m/3m…30m
  • Colors: Blue/grey/black/green/yellow/red/white…
  • Package:1pcs/PE bag
  • Approvals:CE, RoHS&REACH
  • Warranty: Lifetime

Whatsapp Now
Require A Quote

Easy Link’s 10Gigabit 28AWG Bare Copper Unshielded(UTP)Cat6a Ultra Thin Patch Cable is a great solution for high-density data center cabinets, as well as in limited spaces that need cabling. Also, it allows PoE by using 28awg wires, and it realized to make the cable diameter as small as 3.8mm; crossover design minimizes Near-End Crosstalk (NEXT) levels and interference from the electromagnetic field, and successfully passes Cat6a Fluke Chanel Test. Allows to support 500MHz bandwidth networking, and works with the cable modem, DSL modem, router, hub, patch panel, or other network-enabled devices.

Physical Characteristics

• Cable Type – Cat6A UTP
• Connector Type(s) – RJ45 Male
• Wiring Scheme – T568A or T568B
• Temperature Rating – -20°C to +75°C
• Voltage Rating – 30V

———————————————————————————————————————————————

Conductor (Qty. 4 twisted pair)

• Conductor Type – 28AWG(7/0.12), Bare Copper
• Insulation – HDPE
• Dimeter – 0.80±0.05mm
• Pair Identification:
• Pair1=Orange, Orange-White
• Pair2=Blue, Blue-White
• Pair3=Green, Green-White
• Pair4=Brown, Brown-White

Connector Type (Qty. 2)

• Connector Type – Unshielded 8P8C (RJ45)
• Gender – Male
• Connector Material – PC
• Contact Material – Copper Alloy, Gold Plating – 50µm
• Hood Material – Molded PVC

Overall Cable

• Jacket – PVC/LSZH/TPE
• Minimum Average Thickness – 0.30mm
• Outer Diameter – 3.8 ± 0.15mm

———————————————————————————————————————————————

Electrical Characteristics

• Conductor DC Resistance – 22.7Ω/100m (maximum)
• Impedance – 100Ω
• Capacitance – 5600pf/100m
• Propagation Delay – 545ns/100m (maximum)
• Delay Skew – 45ns/100m (maximum)

———————————————————————————————————————————————

Product Application

• Horizontal networks installation
• 10Gigabit; Gigabit 1000 BASE-T; 100 BASE-T; 10 BASE-T (IEEE 802.3)
• Adapters, Hubs, Switches, Routers, DSL/Cable Modems, Patch Panels etc.



  • Ultra Slim CAT6 28AWG Patch Cables, are much lighter and more flexible while still supporting Gigabit Ethernet.
  • The Snagless boot design protects the locking clips on the RJ45 connectors from being damaged or snapped off during installation.
  • It exceeds the performance of the Cat6 ethernet network cable standard and offers a cost-effective solution for indoor Gigabit Ethernet data center applications.
